IQ windowdrives
22
Setting parameters
6.6 Mode of operation push button
à The key interface (IQ gear) is connected.
à For the key interface (IQ gear) to be able to be used, the polarity must be set to "close".
In the mode of operation push button, a distinction is made between the following operating modes:
à Self-locking;
In the self-locking mode of operation, the window continues to open after the push button has been pressed,
even if the key is released again.
The movement only stops when the end position (ventilation stroke parameters set) has been reached. During
closing, the window moves to the closed position.
To stop the movement in an intermediate position, the stop condition must be dened (see Section 6.7).
à Dead-man;
In the dead-man mode of operation the window opens or closes as long as the respective push button is kept
pressed.
The operating mode push buttons are set as described in Section 6.6.
6.7 Stop condition
à The key interface (IQ gear) is connected.
The following choice can be made under the item "stop condition":
à Same key:
The window movement is stopped by pressing the same key. If the window is opening and "open" is pressed
again, the movement stops.
à Dierent key:
The window movement is stopped by pressing the other key. If the window is opening and "close" is pressed,
the movement stops.
à Any key:
The window movement is stopped by pressing any key. If the window is opening and one of the keys is
pressed again, the movement stops.
