GGM GUF Series User Manual

18
Setting range
on – Enable
oFF – Disable
oFF – Disable
on – Enable
FWd – FWD
rEv – REV
P0 – Operation data 0
P1 - Operation data 1
P2 - Operation data 2
A.rSt – Alarm reset
E.Err – External error
---- - Not used
SPd – Rotation speed
AL.on – Alarm on
AL.ov – Overvoltage
OvLd – Overload
Tq.LM – Torque limit
MovE – Motor operation
vA – Rotation speed
WnG – Warning
---- - Not used
1 ~ 400 rpm
0 – User setting
Factory
setting
on
oFF
FWd
rEv
P0
P1
A.rSt
SPd
AL.on
MovE
200 rpm
Initial value
0
•When setting the speed increasing ratio to 1.00, the speed reduction ratio
will be effective.
• When setting a longer time in the “overload alarm detection time except
when holding a shaft” parameter, an overload status may continue.
Repeating this condition may result in shorter service life of the motor and
gearhead.
• If a load exceeding the limited duty region was applied or output shaft was
holded, the “overload alarm detection time except when holding a shaft” is
maximum 5 seconds.
Attention
Item
Prevention of operation
at power–on alarm
External I/O function
External input function
X0 input function selection
X1 input function selection
X2 input function selection
X3 input function selection
X4 input function selection
External output function
Y0 output function
selection
Y1 output function
selection
Y2output function
selection
Rotation speed
attainment band
Initialize the parameter
mode
Developer setting
Display
oP.AL
io.En
in
in.0
in.1
in.2
in.3
in.4
oUt
oUt.0
oUt.1
oUt.2
At.bd
init
S.USr
Description
Sets whether to enable or disable the
“prevention of the operation at
power on alarm”
The operation method can be selected
between the front panel and external
input signals.
When operating or stopping the motor
using the external input signals, the
functions of the operation switch,
rotation direction switch, and setting
button can be set to disable.
External input setting.
Assigns the input signals to the
external input terminals.
External output setting.
Assigns the output signals to the
external output terminals.
Sets the band within which the
rotation speed of the motor is
deemedto have reached the set
value.
Restores the value set in the
parameter mode to the factory
setting.
Developer setting
