GGM GUF Series User Manual

2. Confirmation when the product is handed over
- Confirm that the delivered product is the product you ordered.
- If a different product is installed, it will create the risk of injury or fire.
- Contact a nearby retail store if you were delivered an insufficient number of products or
if a damaged product wasdelivered.
1) CONTROLLER
2) user's manual (this manual)
3) optional (extension cable)
------------------- One
------------------- One
If the controller is far away
from the motor, refer to
the optional specification
specified in the table above.
3. Specifications
3
MODEL
length of
extension
cable
KFEW-1 K10FEW-1 1m
KFEW-2 K10FEW-2 2m
KFEW-3 K10FEW-3 3m
KFEW-5 K10FEW-5 5m
KFEW-7 K10FEW-7 7m
KFEW-10 K10FEW-10 10m
200, 400W30, 60, 150W
Part Number
Rated Output Power
(Continuous)
GUF-C-30
30W
GUF-C-60
60W
GUF-C-150
150W
GUF-C-200
200W
GUF-C-400
400W
Rated voltage
Rated frequency
Rated input
current
Maximum
input current
Single-phase : 200~240V / three-phase : 200~240V ( Permissible range ±10 % )
50 / 60 Hz ( Permissible range ±5 % )
Rated Output Current
Rated Torque
Maximum Instantaneous Torque
Rated Speed
Speed Control Range
Speed Regulation
Power
input
Temperature
Humidity
Environment
Input signal
Output signal
3000 r/min
100~4000 r/min
0.5% or less/ Conditions : 0~RatedTorque, Rated Speed, Rated Voltage, Normal Temperature
Use : 0 ~ 40℃(Non-freezing), Storage : -20 ~ 70℃(Non-freezing)
Use : 85%below(Non-condensing), Storage : 85%below(Non-condensing)
No corrosive gas and dust, No splashing water and oil
5 user inputs ( Photocoupler )
3 user outputs ( Photocoupler )
Single-Phase
0.8A
Three-Phase
0.5A
Single-Phase
1.9A
Three-Phase
1.1A
0.17 A
0.1 N.m
0.15 N.m
Single-Phase
1.0A
Three-Phase
0.7A
Single-Phase
2.8A
Three-Phase
1.7A
0.43 A
0.2 N.m
0.3 N.m
Single-Phase
2.0A
Three-Phase
1.2A
Single-Phase
4.5A
Three-Phase
2.6A
0.95 A
0.49 N.m
0.60 N.m
Single-Phase
2.5A
Three-Phase
1.8A
Single-Phase
5.5A
Three-Phase
3.2A
1.60 A
0.65 N.m
1.15 N.m
Single-Phase
4.0A
Three-Phase
3.0A
Single-Phase
7.8A
Three-Phase
5.0A
2.30 A
1.30 N.m
1.80 N.m
Operating
Environment
Input
output

GGM GUF Series Specifications

General
