GHOST
User Manual Status 04/2009 // Spec 2010
10.115
9. Check the installation:
• Actuate the brakes.
• If a brake block continues to be in contact with the wheel rim, this can
indicate incorrect mounting of the hub in the fork ends.
• In this case release the quick-release lever again, check and correct the
position of the hub and close the quick-release lever again.
• The brake (with rim brakes) does not have to be opened for this. If this does
not improve the situation, contact your dealer immediately.
10.2 Install and remove saddle post with saddle
Danger of personal injury and material damage!
An incorrectly installed saddle post can lead to dangerous riding situations,
falls, accidents and material damage.
Be sure to have your dealer show you how to correctly remove and install the
saddle post.
Practice these operations at least once under his supervision and control.
Carry out removal and installation only when you are sure that you can do this
correctly.
You can remove the saddle post with saddle for transport and then install it again later.
The saddle post is secured in the saddle tube of the frame using a clamp with either a quick-
release lever or a hex. socket head screw.
In the case of carbon saddle supports, special forms with two screws may be installed.
