Giant Crest 34 - Page 15

15
4
打開 Low speed compression。
Open the Low Speed Compression knob.
5
壓縮上、下叉腳。
Compress upper and lower legs.
6
鎖緊阻尼側底部螺絲，扭力值 7.5Nm。
Tighten the damper bolt to 7.5Nm.
Note: Make sure the bolt is tightened to
recommended torque value.
7
拉長上下叉，氣壓側打氣至 100psi，推出連桿。
註：請確實鎖緊氣壓側螺母至標準扭力值。
Pull out the lower legs from the stanchions.
Pump the air chamber to 100 psi to push out the connecting rod.
Pump 100 psi
