Giant Crest 34 - Air Spring Side Assembly

12
氣壓室組裝 Air Spring Side Assembly
1
活塞及連桿抹上
Slick honey
，如下圖，約
3ml。
Apply 3ml of Slick Honey lubricant on the piston and connecting rod, as shown below.
2
以旋轉的手勢裝入，請參考影片。
Insert and rotate the piston to set. Please reference the Crest service video for complete instructions on this step.
3
活塞連桿外露長度：
100mm 行程: 小於 100mm
120mm 行程: 小於 120mm
Necessary length of connecting rod
outside the chamber:
100mm travel: less than 100mm.
120mm travel: less than 120mm.
