Giant Crest 34 - Wiper Seal Replacement

32
防塵套更換 Wiper Seal Replacement
1
取出油泡棉，浸泡至 Mobil SHC 627。
Remove sponges and soak in Mobil SHC
627. Other oils may be used, please check
with Giant ASQA for confirmation
2
使用開口扳手拆下防塵套，清潔表面。
Remove wiper seal using an open wrench.
Clean the inside of lower leg.
3
使用特殊工具裝上防塵套，再裝入下叉腳。
Assemble the wiper seal with 912WPSFT34A1K Tool for Wiper Seal Assembly.
Knock the wiper seal into the lower leg using a plastic mallet.
1
裝回油泡棉。
Re-insert sponge.
Sponge
DU
