Installation
Extension
If you need to install an extension, this should be similar to the drain hose.
The extension should not be greater than 4 metres; otherwise, it may reduce the efciency
of the washing.
Electrical connection
For your safety, have an electrician you trust who check the condition of the electrical network
of the location where the Dishwasher will be installed and, for more information, contact the
Electrolux Authorized Service.
Make sure that the voltage value in the household corresponds to the one stated on the
identication label. Check also if the electrical system supports the maximum current stated
in the manual. Only then put the plug of the power cord into the outlet, which must be
properly grounded.
* The voltage levels of the power with which this appliance operates are set out
in “Procedures for the Distribution of Electricity in the National Electric System
(PRODIST)” of the ANEEL (National Agency of Electric Power).
If the power supply of the appliance is outside the limits shown in the table Allowable
Voltage Variation, ask the electric utility company the adequacy of the levels of voltage
and install a voltage regulator (stabilizer) with power equal to or higher than 2000 VA.
Before connecting, check if the voltage of the outlet
where the appliance will be connected is equal to that
indicated on the label located next to the plug (on
the power cord) or on the identication label of the
Dishwasher.
Connect your Dishwasher to a dedicated power outlet,
do not use extension cords, or type “T” connectors
(Benjamin).
This type of connection can cause overload in the
electrical network, affecting the operation and resulting
in accidents.
Do not cut or remove, under any circumstances, the
grounding prong of the plug on the power cord.
Allowable Voltage Variation*
Voltage (V) Minimum (V) Maximum (V)
127 116 133
220 201 231
