- 4 -
GA-H110-D3 Motherboard Layout
Box Contents
5 GA-H110-D3 motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
SYS_FAN1
SYS_FAN3
LGA1151
ATX
GA-H110-D3
SPDIF_O
AUDIO
DDR4_1
DDR4_2
BAT
ATX_12V_2X4
Intel
®
H110
F_USB30
R_USB30
CODEC
CLR_CMOS
M_BIOS
B_BIOS
COMAVGA
LPT
USB_LAN
PCIEX16
PCIEX1_1
PCIEX1_2
PCIEX1_3
PCI1
PCI2
PCI3
iTE
®
Super I/O
Realtek
®
GbE LAN
PCIe to PCI
Bridge
F_USB1F_USB2F_AUDIO
TPM
F_PANELSYS_FAN2
SATA3
1 3
0 2
42J60J80J
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
M2J_SATA
M.2
