GIGA-BYTE TECHNOLOGY GA-H270-HD3P User Manual

1-7 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) CPU/DRAM/VGA/BOOT
6)
SATAEXPRESS
7) SATA30/1/2/3/4/5
8) M2A_32G
9) BAT
10) F_PANEL
11) SPDIF_O
12) F_ AUDIO
13) F_USB30_1/F_USB30_2
14) F_USB1/F_USB2
15) COMA
16) LPT
17) TPM
18) CLR_CMOS
13
1
4
1412
9
11
3
5
4
15 16
8
17
4
2
7
6
7
18
10
- 12 -
