GIGA-BYTE TECHNOLOGY GA-H270M-D3H User Manual

Storage Interface - 6 x SATA 6Gb/s connectors
 - SupportforRAID0,RAID1,RAID5,andRAID10
 * Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
USB  Chipset:
- 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1x8-pinATX12Vpowerconnector
 1 x M.2 Socket 3 connector
 2 x SATA Express connectors
 6 x SATA 6Gb/s connectors
 1 x CPU fan header
 3 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header
 1 x serial port header
 1 x parallel port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x D-Sub port
 1xDVI-Dport
 1 x HDMI port
 1 x USB Type-C
™
port, with USB 3.1 Gen 1 support
 4 x USB 3.1 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1xRJ-45port
 6xaudiojacks(Center/SubwooferSpeakerOut,RearSpeakerOut,SideSpeaker
Out, Line In, Line Out, Mic In)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltagedetection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
- 7 -
