1-9 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) SYS_FAN3_PUMP
6) CPU_OPT
7) LED_C
8) SATA EXPRESS
9) SATA3 0/1/2/3/4/5
10) U2_32G
11) M2M_32G/M2A_32G
12) F_PANEL
13) F_ AUDIO
14) SPDIF_O
15) GAIN
16) F_USB30_1/F_USB30_2
17) F_USB1/F_USB2
18) TPM
19) THB_C
20) CLR_CMOS
21) BAT
22) CPU/VGA/DRAM/BOOT
4
51911 12 22
9
2
8
9
8
16
181315 14
1
4
7
10
20
21
11
17
36
- 14 -
