8) SATA3 0/1/2/3/4/5 (SATA 6Gb/s Connectors)
The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA
1.5Gb/s standard. Each SATA connector supports a single SATA device. The Intel
®
Pin No.
1 GND
2 TXP
3 TXN
4 GND
5
6
7 GND
SATA3
5 3 1
4 2 0
1
17
7
7) LED_C (RGB LED Strip Header)
rating of 2A (12V) and maximum length of 2m.
Pin No.
1 12V
2 G
3
4 B
1
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
triangle on the plug) of the LED strip must be connected to Pin 1 (12V) of
the digital LED strip header. Incorrect connection may lead to the damage
of the LED strip.
LED Strip
1
12V
- 16 -
