GIGA-BYTE TECHNOLOGY Z790 AORUS PRO X User Manual

- 5 -
LGA1700 CPU
CPU CLK+/- (80~800 MHz)
DMI 4.0
Intel
®
Z790
PCI Express 5.0 Bus
1-2 Motherboard Block Diagram
SPI
Bus
PCI Express Bus
x4
2 PCI Express x4
TPM
BIOS
DDI
DDI
1 USB Type-C
®
, with USB 2.0
support & DisplayPort Alt mode
DisplayPort In
Switch
DDI
1 HDMI
LAN
RJ45
x1
Realtek
®
5GbE LAN
x1
M.2 WIFI
4 SATA 6Gb/s
(SATA3 4~7)
DDR5 5600
(Note 1)
/5200
(Note 1)
/4800/4400 MT/s
PCI Express 4.0 Bus
x4 x4 x4
3 M.2 Socket 3
(M2Q_SB, M2P_SB, M2M_SB)
x4
PCI Express 4.0 Bus
1 M.2 Socket 3
(M2A_CPU)
1 PCI Express x16
x16
x16
1 PCI Express x8
1 M.2 Socket 3
(M2C_CPU)
x4x8
Switch
or
(Note 1) Actual support may vary by CPU.
(Note 2) Only for Z790 AORUS PRO X.
4 USB 2.0/1.1
4 USB 3.2 Gen 1
2 USB Type-C
®
,
with USB 3.2 Gen 2x2 support
2 USB 3.2 Gen 2 Type-A
2 USB 3.2 Gen 1
2 USB 2.0/1.1
USB 3.2
Gen 1 Hub
USB 2.0
Hub
eSPI
Bus
iTE
®
Super I/O
1 USB Type-C
®
,
with USB 3.2 Gen 2 support &
DisplayPort 1.2 Alt mode
(Note 2)
Line Out
Mic
S/PDIF Out
CODEC
CNVi
(Note 2)

GIGA-BYTE TECHNOLOGY Z790 AORUS PRO X Specifications

General

Brand	GIGA-BYTE TECHNOLOGY
Model	Z790 AORUS PRO X
Category	Motherboard
Language	English
