- 22 -
2-8 Internal Connectors
1) ATX_12V_2X4_1/ATX_12V_2X4_2
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) SYS_FAN5/6_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) ARGB_V2_1/ARGB_V2_2/ARGB_V2_3
9) LED_C
10) NOISE_SENSOR
11) SATA3 4/5/6/7
12) M2C_CPU/M2A_CPU/M2Q_SB/M2P_SB/M2M_SB
13) F_PANEL
14) F_AUDIO
15) USBDP
16) F_U320G
17) F_U32
18) F_USB1/F_USB2
19) SPI_TPM
20) THB_C1/THB_USB4_C2
21) CLR_CMOS
22) RST
23) BAT
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1321
17
15
10
12
5
2
5
7
11
20
16
7 418814 8 19
1
9
23
22
12
12
12
12
3 86
