Gigabyte 5AX - Page 52

Hardware Installtion
3-4
t
JP5: Wake on Lan
Pin No. Function
1 +5V SB
2 GND
3 Signal
t
FAN PWR: CPU cooling FAN Power Connector
Pin No. Function
1 GND.
2 +12V
3 SENSE
t
JP3: Keyboard Power On/Off Connector
Pin No. Function
1,2 Close Enabled Keyboard power on.
2,3 Close Disabled Keyboard power on. (Default)
t
JP11: VCC3 Connector
Pin No. Function
1-2,3-4 Close VCC3(PSU)<->VCC3(MB)
1-3,2-4 Close VCC3(PSU)<
≠
>VCC3(MB)
t
IR :Infrared Connector
PIN No. Function
1 Power +
2 FIR
3 IR Data Input
4 GND
5 IR Data Output
6 Over Current
t
JP13: VCC Voltage Setting
Pin No. Function
1,2 Close VCC3=3.58
2,3 Close VCC3=3.3
