BIOS Configuration
4-31
• RTC Alarm Controller
The default value is Disabled.
Disabled Disable this function.
Enabled Enable alarm function to POWER ON system.
If RTC Alarm Controller is Enabled.
Date Alarm : NA,1~31
Hour Alarm : 0~24
MinuteAlarm : 0~59
•
Onboard IrDA Port
The default value is Disabled
Disabled
Disable onboard IrDA port.
2E0H
Enable onboard IrDA port and address is 2E0.
3E0H
Enable onboard IrDA port and address is 3E0.
2E8H
Enable onboard IrDA port and address is 2E8.
3E8H
Enable onboard IrDA port and address is 3E8.
2F8H
Enable onboard IrDA port and address is 2F8.
3F8H
Enable onboard IrDA port and address is 3F8.
• IR IRQ Seclect
The default value is IRQ 10
IRQ 10 ~ 11,4~3
Assign Available IRQ# for Ir .
• IrDA Mode
The default value is IrDA1.0
IrDA1.0
Support Ir Specification 1.0.
IrDA1.1
Support Ir Specification 1.1.
