- 4 -
B365M D3V Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 B365M D3V Motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS_USB
CPU_FAN
SYS_FAN
LGA1151
ATX
B365M D3V
F_AUDIO
AUDIO
BAT
ATX_12V_2X4
Intel
®
B365
CODEC
CLR_CMOS
M_BIOS
VGA
LPT
USB30_LAN
PCIEX16
PCIEX1_1
PCI
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1
TPM
F_USB2
F_PANEL
SATA3
0 1 2
3 4 5
DVI
80 60
42
B_BIOS
COM
F_USB30
R_USB30
M2A
DDR4_2
DDR4_1
PCIEX1_2
PCIe to PCI
Bridge
