Gigabyte BRIX User Manual

- 27 -
System Hardware Installation
3-3 Installing the Memory
Read the following guidelines before you begin to install the memory:
• Make sure that the sysytem supports the memory. It is recommended that memory of the same
capacity, brand, speed, and chips be used.
• Always turn off the computer and unplug the power cord from the power outlet before installing
the memory to prevent hardware damage.
• Memory modules have a foolproof design. A memory module can be installed in only one
direction. If you are unable to insert the memory, switch the direction.
Follow these instructions to Install the Memory(SO-DIMM DDR4):
1. Carefully insert SO-DIMM memory modules.
(
小心並由下層至上層安裝 SO-DIMM 記憶體於記憶體插槽
󾗘
2. Push down until the modules click into place.
(
當記憶體固定於插槽後，再輕輕下壓至定點
󾗘
3. Carefully insert SO-DIMM memory modules.
(
安裝下層記憶體後，重覆前述動作安裝上層記憶體
󾗘
4
. Push down until the modules click into place.
(
當記憶體固定於插槽後，再輕輕下壓至定點
󾗘
1
2
3
4
Arbeitsspeicher Installation: SO-DIMM DDR4 / Installation de la mémoire : SO-DIMM DDR4 / Instalación de la
memoria: SO-DIMM DDR4 / Instalação de memória: SO-DIMM DDR4 / Installazione della memoria: SO-DIMM
DDR4 / Установка модулей памяти: SO-DIMM DDR4 / Instalacja pamięci: SO-DIMM DDR4 / Hafıza Yüklemesi:
SO-DIMM DDR4 /
󲶿󸄅󸍚󳣫󺂴󽘪
SO-DIMM DDR4 /
󱯜󲵙󲶿󸃔󽘪
SO-DIMM DDR4
󽘪
SO-DIMM DDR4
󻟃󻠗󻜛󾖴󻺓󼯇
SO-DIMM DDR4

Gigabyte BRIX Specifications

General

Processor Options	Intel Core i3/i5/i7
Memory Slots	2 x SO-DIMM
Max Memory	32GB or 64GB (depending on the specific model)
Storage	M.2 SSD, 2.5" HDD/SSD (depending on model)
Graphics	Intel UHD Graphics (depending on the specific processor)
Networking	Gigabit Ethernet, Wi-Fi (depending on the specific model)
USB Ports	USB-C (depending on model)
Video Output	HDMI (depending on model)
Audio	3.5mm audio jack
Operating System	depending on model
Power Supply	External power adapter
Weight	depending on model
