Connectors
8
Connectors
COM A / COM B / LPT Port
COM A
LPT Port
COM B
USB Connector
Pin No. Definition
1 USB V0
2 USB D0-
3 USB D0+
4 GND
5 USB V1
6 USB D1-
7 USB D1+
8 GND
1
2
3
4
8
7
6 5
