BIOS Setup- 39 -
English
Legacy USB storage detect
This option allows users to decide whether to detect USB storage devices, including USB flash
drives and USB hard drives during POST.
Enabled BIOS will scan all USB storage devices. (Default value)
Disabled Disable this function.
Azalia Codec
Auto Auto detect Azalia audio function. (Default value)
Disabled Disable Azalia audio function.
Onboard H/W 1394
Enabled Enable onboard IEEE 1394 function. (Default value)
Disabled Disable this function.
Onboard H/W LAN
Enabled Enable onboard H/W LAN function. (Default value)
Disabled Disable this function.
SMART LAN
CMOS Setup Utility-Copyright (C) 1984-2006 Award Software
SMART LAN
Item Help
Menu Level
Start detecting at Port.....
Pair1-2 Status = Normal / Length = N/A
Pair3-6 Status = Normal / Length = N/A
Pair4-5 Status = Normal / Length = N/A
Pair7-8 Status = Normal / Length = N/A
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
This motherboard incorporates cable diagnostic feature designed to detect the status of the attached LAN
cable. This feature will detect cabling issue and report the approximate distance to the fault or short.
Refer to the following information for diagnosing your LAN cable:
When LAN Cable Is Functioning Normally...
1. If no cable problem is detected on the LAN cable connected to a Gigabit hub, the Status fields
of Pair 1-2, Pair 3-6, Pair 4-5, and Pair 7-8 will show Normal and the Length fields will show
N/A, as shown in the figure above.
2. If no cable problem is detected on the LAN cable connected to a 10/100 Mbps hub, the Status
fields of Pair 1-2 and Pair 3-6 will show Normal and the Length fields will show N/A.
However, because Pair 4-5 and Pair 7-8 are not used in a 10/100 Mbps environment, their
Status fields will show Short or Open, and the length shown is the approximate length of the
attached LAN cable.
When a Cable Problem Occurs...
If a cable problem occurs on a specified pair of wires, the Status field will show Short or Open
and the length shown will be the approximate distance to the fault or short.
For example, if it shows Pair1-2 Status = Short / Length = 1.6m,
it means that a fault or short might occur at about 1.6m on Pair 1-2.
