GA-965P-DS3P Motherboard - 40 -
English
OnBoard LAN Boot ROM
This function decide whether to invoke the boot ROM of the onboard LAN chip.
Enabled Enable this function.
Disabled Disable this function. (Default value)
Onboard SATA/IDE Device
This function allows users to enable or disable the SATA/IDE ports controlled by the Gigabyte
SATA2 controller.
Enabled Enable this function. (Default value)
Disabled Disable this function.
Onboard SATA/IDE Ctrl Mode
This function allows users to decide the operating mode of the SATA/IDE ports controlled by the
Gigabyte SATA2 controller.
IDE Set the SATA channel to IDE mode. (Default value)
AHCI Set the SATA channel to AHCI mode. Advanced Host Controller Inteface (AHCI)
is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
For more details about AHCI, please visit Intel's website.
RAID/IDE Set the SATA channel to RAID mode and IDE channel to IDE mode.
Onboard Serial Port 1
Auto BIOS will automatically setup the port 1 address.
3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8/IRQ4. (Default value)
2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8/IRQ3.
3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8/IRQ4.
2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8/IRQ3.
Disabled Disable onboard Serial port 1.
Onboard Parallel Port
Disabled Disable onboard LPT port.
378/IRQ7 Enable onboard LPT port and address is 378/IRQ7. (Default value)
278/IRQ5 Enable onboard LPT port and address is 278/IRQ5.
3BC/IRQ7 Enable onboard LPT port and address is 3BC/IRQ7.
Parallel Port Mode
SPP Using Parallel port as Standard Parallel Port. (Default value)
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mode.
When No LAN Cable Is Attached...
If no LAN cable is attached to the motherboard, the Status fields of all four pairs of wires will show
Open and the Length fields show 0.0m.
