- 11 - Hardware Installation
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x APU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 2.0/1.1 header
1 x debug card header
* This port is mainly used by repair technicians for debugging and problem
diagnosis.
1 x chassis intrusion header
1 x power LED header
1 x clearing CMOS jumper
Back Panel
Connectors
1 x DVI-D port
1 x HDMI port
1 x optical S/PDIF Out connector
1 x eSATA 6Gb/s port
2 x USB 2.0/1.1 ports
4 x USB 3.0/2.0 ports
1 x RJ-45 port
3 x audio jacks (Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller iTE IT8720 chip
Hardware
Monitor
System voltage detection
APU/System temperature detection
APU/System fan speed detection
BIOS 2 x 32 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
Support for Smart Recovery
Support for Auto Green
Support for ON/OFF Charge
Support for 3TB+ Unlock
Support for Q-Share
