Hardware Installation - 10 -
1-2 Product Specications
APU FM1 Socket:
- AMD A series processors/AMD E2 series processors
(Go to GIGABYTE's website for the latest APU support list.)
Chipset AMD A75
Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
APU:
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
(All integrated graphics ports do not support Hot plug. If you want to change to
another graphics port when the computer is on, be sure to turn off the computer
rst.)
Audio Realtek ALC889 codec
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
Support for Dolby
®
Home Theater
Support for S/PDIF Out
LAN 1 x Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
(The PCI Express x16 slot conforms to the PCI Express 2.0 standard.)
Storage Interface Chipset:
- 4 x SATA 6Gb/s connectors supporting up to 4 SATA 6Gb/s devices
- 1 x eSATA 6Gb/s port on the back panel supporting up to 1 SATA 6Gb/s
device
* Actual transfer rate is dependent on the device being connected.
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB Chipset:
- Up to 4 USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available
through the internal USB headers)
- Up to 4 USB 3.0/2.0 ports on the back panel
