- 7 -
GA-A75N-USB3 Motherboard Layout
R_USB30
CPU_FAN
Socket FM1
ATX
GA-A75N-USB3
AUDIO
PCIEX16
(Note 2)
DDR3_1
DDR3_2
BAT
Realtek
GbE LAN
F_PANEL
ATX_12V
AMD A75
iTE
IT8720
USB_ESATA
CODEC
DVI
HDMI_SPDIF
USB30_LAN
M_BIOSB_BIOS
CLR_CMOS
SATA3_3
DB_PORT
(Note 1)
SATA3_0 SATA3_1
SPDIF_O
SYS_FAN1
F_AUDIO
SATA3_2
PWR_LED
F_USB1
CI1
(Note 1) This port is mainly used by repair technicians for debugging and problem diagnosis.
(Note 2) Actual product appearance may slightly differ from the product illustrated.
