GA-A75N-USB3 Motherboard Block Diagram
AMD APU
UMI
APU CLK+/- (100 MHz)
DDR3 2000(O.C.)1866/1600/1333/1066 MHz
PCI Express Bus
PCIe CLK
(100 MHz)
1 PCI Express x16
DVI-D
AMD A75
iTE
IT8720
LPC
Bus
Line Out (Front Speaker Out)
MIC (Center/Subwoofer Speaker Out)
Line In (Rear Speaker Out)
S/PDIF Out
CODEC
Dual BIOS
PCIe CLK
(100 MHz)
PCI Express Bus
4 USB 2.0/1.1
4 USB 3.0/2.0
LAN
RJ45
x1
Realtek
GbE LAN
x16
5 SATA 6Gb/s
HDMI
DISP CLK+/- (100 MHz)
