Gigabyte GA-P67-DS3-B3 User Manual

BIOS Setup - 34 -

M.I.T. Current Status
This screen provides information on CPU/memory frequencies/parameters.

Advanced Frequency Settings
(Note 1) This item is present only if you install a memory module that supports this feature.
(Note 2) This item is present only if you install a CPU that supports this feature. For more information about
Intel CPUs' unique features, please visit Intel's website.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Frequency Settings
CPU Clock Ratio [31X]
CPU Frequency 3.10GHz (100x31)

Advanced CPU Core Features [Press Enter]
>>>>> Standard Clock Control
BCLK/DMI/PEG Clock Control
j
[Disabled]
x BCLK/DMI/PEG Frequency (0.1MHz)
j
1000 100.0MHz
 ExtremeMemoryProle(X.M.P.)
(Note 1)
j
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level


Advanced CPU Core Features
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced CPU Core Features
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CPU Clock Ratio [31X]
CPU Frequency 3.10GHz (100x31)
Internal CPU PLL Overvoltage [Auto]
Real-Time Ratio Changes In OS
(Note 2)
j
[Disabled]
Intel(R) Turbo Boost Tech.
(Note 2)
[Auto]
-Turbo Ratio(1-Core)
(Note 2)
36 [Auto]
-Turbo Ratio(2-Core)
(Note 2)
34 [Auto]
-Turbo Ratio(3-Core)
(Note 2)
32 [Auto]
-Turbo Ratio(4-Core)
(Note 2)
31 [Auto]
-Turbo Power Limit(Watts) 95 [Auto]
-Core Current Limit(Amps) 97 [Auto]
CPU Cores Enabled
(Note 2)
[All]
CPU Multi-Threading
(Note 2)
[Enabled]
CPU Enhanced Halt (C1E)
(Note 2)
[Auto]
C3/C6 State Support
(Note 2)
[Auto]
CPU Thermal Monitor
(Note 2)
[Auto]
CPU EIST Function
(Note 2)
[Auto]
Bi-Directional PROCHOT
(Note 2)
[Auto]
CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being installed.
j
Only for GA-P67-DS3-B3.

Gigabyte GA-P67-DS3-B3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7/Vista/XP
On-board graphics card	No
RAID levels	0, 1, 5, 10
Bundled software	Norton Internet Security
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	215 mm
Width	305 mm
