GA-X38-DS4 Motherboard - 22 -
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable
has been securely attached to the connector on the motherboard.
1) ATX_12V_2X
2) ATX
3) CPU_FAN
4) SYS_FAN1/SYS_FAN2
5) PWR_FAN
6) NB_FAN
7) PCIE_12V
8) FDD
9) IDE
10) SATAII0/1/2/3/4/5
11) PWR_LED
12) BAT
13) F_PANEL
14) F_AUDIO
15) CD_IN
16) SPDIF_IN
17) SPDIF_O
18) F_USB1/F_USB2
19) F_1394
20) LPT
21) TPM
22) COM
23) CI
24) CLR_CMOS
2
1
3
19
8
10
9
14
20
15
5
7
13
6
4
23
4
16
17
12
11
101821 22
24
