Gigabyte H310M DS2V DDR3 User Manual

Copyright
© 2018 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or
by any means without GIGABYTE's prior written permission.
 In order to assist in the use of this product, carefully read the User's Manual.
 For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means
the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard
BIOS, drivers, or when looking for technical information.
Example:
Motherboard
H310M DS2V DDR3
Oct. 26, 2018
Oct. 26, 2018
Motherboard
H310M DS2V DDR3

Gigabyte H310M DS2V DDR3 Specifications

General

Max Memory	32 GB
Memory Architecture	Dual Channel
Dimensions	22.6cm x 17.4cm
CPU	Supports 8th and 9th Gen Intel Core i7/i5/i3/Pentium/Celeron processors
Chipset	Intel H310
Memory Slots	2
Memory Type	DDR3
Graphics	Integrated Graphics Processor- Intel® HD Graphics support
Audio	Realtek® ALC887 codec
LAN	Realtek® GbE LAN chip (10/100/1000 Mbit)
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4
USB Ports	4 x USB 3.1 Gen 1 (2 on back panel, 2 via internal header), 6 x USB 2.0/1.1 (2 on back panel)
Back Panel Connectors	1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 2 x USB 3.1 Gen 1 ports; 1 x RJ-45 port; 3 x audio jacks
Internal I/O Connectors	1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 4 x SATA 6Gb/s connectors; 1 x CPU fan header; 1 x system fan header; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.1 Gen 1 header; 1 x serial port header; 1 x Clear CMOS jumper
Form Factor	Micro ATX
Video Outputs	D-Sub

Summary

H310M DS2V DDR3 Motherboard Layout

Chapter 1 Hardware Installation

Installation Precautions

Guidelines for safely installing hardware components to prevent damage from static discharge and improper handling.

Product Specifications

Details key hardware specifications of the motherboard, including CPU, chipset, memory, and expansion slots.

Installing the CPU

Step-by-step instructions for safely installing the Central Processing Unit (CPU) onto the motherboard socket.

Installing the Memory

Procedure for installing RAM modules into DIMM sockets, including dual-channel configuration guidelines.

Installing an Expansion Card

Instructions for installing add-in cards, such as graphics or network cards, into PCI Express slots.

Back Panel Connectors

Identifies and describes the function of all external connectors on the motherboard's rear I/O panel.

Internal Connectors

Details the location and function of various internal connectors on the motherboard for system components and headers.

Chapter 2 BIOS Setup

Startup Screen

Description of the initial GIGABYTE logo screen that appears during system boot-up, showing function keys.

The Main Menu

Overview of the BIOS Setup main interface, explaining navigation methods and essential function keys.

Μ.Ι.Τ.

Advanced settings for system tuning, including frequency, voltage, and core settings for performance optimization.

System

Provides system information like model name and BIOS version, and allows setting system language and date/time.

BIOS

Configuration options for boot order, security settings, fast boot, and other system boot behaviors.

Peripherals

Settings for managing onboard devices such as LAN, audio controllers, USB ports, and other integrated peripherals.

Chipset

Configuration options related to the motherboard's chipset, including internal graphics, DVMT, and audio controllers.

Power

Settings for managing system power states, including AC BACK, wake-up events, and power saving features.

Save & Exit

Options for saving BIOS changes, loading default settings, and exiting the BIOS Setup utility.

Chapter 3 Appendix

Drivers Installation

Instructions on how to install necessary motherboard drivers using the provided utility or individually.

Regulatory Statements

Important legal and environmental notices, including RoHS, WEEE directives, and FCC compliance statements.

Contact Us

Information on how to contact GIGABYTE for technical support, sales inquiries, and general assistance.
