Gigabyte M34WQ User Manual

LCD Monitor User's Manual
-
19
-
USING THE DEVICE
Turning the Power On/O
Make sure the power switch next to the AC power input jack is switched
to ON.
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of
the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor. The Power LED will
light in white, indicating the monitor is ready to use.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the
monitor by moving the Control button down ( ). Refer to page 24 .

Gigabyte M34WQ Specifications

General

Color depth	8 bit
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Viewable size, vertical	334.8 mm
sRGB coverage (typical)	117 %
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	799.8 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	3440 x 1440
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 400
RMS rated power	3 W
Number of speakers	2
Product color	Black
Market positioning	Gaming
DisplayPort version	1.4
Headphone connectivity	3.5 mm
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	127 W
Power consumption (off)	0.3 W
Power consumption (typical)	- W
Power consumption (PowerSave)	0.5 W
Cables included	DisplayPort, HDMI, USB
Package type	Box
Package depth	198 mm
Package width	1060 mm
Package height	527 mm
Package weight	13470 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.3 mm
Width (with stand)	817.7 mm
Height (with stand)	548.8 mm
Weight (with stand)	10220 g
Depth (without stand)	67.5 mm
Height (without stand)	368.7 mm
Weight (without stand)	7050 g
