Chapter 3 Appendix
Refer to the following steps to install a 2.5" drive:
1. Remove the two screws from the side panel. Then pull out the side panel.
2. Release the thumb screw from the 2.5" drive bracket to take out the bracket.
3. Use the bundled screws to secure your 2.5" drive to the bracket.
4. Replace the bracket with the installed 2.5" drive in the desktop computer.
Then connect the hard drive data and power cables to the 2.5" drive.
5. Replace the side panel and secure it with the screws you previously removed.
1
2
3
3-1 Installing a 2.5" Drive
- 19 -
