Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX1 11) BP_1
2) P12V_AUX1 12) SPI_TPM
3) P12V_AUX2 13) IPMB
4) CPU0_FAN 14) CN_NCSI
5) SYS_FAN1/2//3
/
4 15) LED_BMC
6) SYS_FAN5 16) BAT
7) SYS_FAN6 17) CASE_OPEN
8) PMBUS
9) F_USB1
10) FP_1
CPU0
DIMM_P0_D0 DIMM_P0_C0 DIMM_P0_B0 DIMM_P0_H0 DIMM_P0_E0 DIMM_P0_F0 DIMM_P0_A0 DIMM_P0_G0
37
14
16
1
2
4
5 6
8
9
10
11
12
13
15
17
