BIOS Setup
2-4-4 BMC Network Conguration
Parameter
Description
BMCnetworkconguration
Select NCSI and Dedicated
LAN
Options available: Do Nothing, Model1(Dedicated), Model2(NCSI),
Mode3(Failover). Default setting is Do Nothing.
Lan Channel 1
CongurationAddresssource
SelectstocongureLANchannelparametersstaticallyordynamically
(DHCP).
Optionsavailable:Unspecied,Static,DynamicBmcDhcp.Defaultsetting
is DynamicBmcDhcp.
Station IP address
Displays IP Address information.
Subnet mask
Displays Subnet Mask information.
Please note that the IP address must be in three digitals, for example,
192.168.000.001.
Router IP address
Displays the Router IP Address information.
Station MAC address
Displays the MAC Address information.
Real-time get BMC network
address
Press [Enter] will set LAN mode and Address source and then get IP,
Subnet, Gateway and MAC address.
