Gigabyte MS03-CE0 User Manual

- 67 -
BIOS Setup
Parameter
Description
SATA And RST
Conguration/
SATA Controller And RST
Conguration(continued)

Port 0/1/2/3/4/5/6/7
– Enable/Disable Port 0/1/2/3/4/5/6/7 device.
– Options available: Enabled, Disabled. Default setting is Enabled.

Hot Plug (for Port 0/1/2/3/4/5/6/7)
– Enable/Disable HDD Hot-Plug function.
– Options available: Enabled, Disabled. Default setting is Enabled.

Spin Up Device (for Port 0/1/2/3/4/5/6/7)
– On an edge detect from 0 to 1, the PCH starts a COM reset
initialization to the device.
– Options available: Enabled, Disabled. Default setting is Disabled.
SATA And RST
Conguration/
sSATA Controller And RST
Conguration

SATAConguration
– Enable/Disable SATA controller.
– Options available: Enabled, Disabled. Default setting is Enabled.

SATA Mode Selection
– ConguresonchipSATAtype.
– AHCI Mode: When set to AHCI, the SATA controller enables its AHCI
functionality. Then the RAID function is disabled and cannot be access
the RAID setup utility at boot time.
– RAID Mode: When set to RAID, the SATA controller enables both its
RAID and AHCI functions. You will be allowed to access the RAID
setup utility at boot time.
– Options available: AHCI, RAID. Default setting is AHCI.

RAID Device ID
(Note)
– Choose RAID Device ID.
– Options available: Client, Alternate, Server. Default setting is Server
.

SATA Port 4/5/6/7
– ThecategoryidentiessSATAharddrivesthatareinstalledinthe
computer. System will automatically detect HDD type.

SATA Port 4/5/6/7
– Enable/Disable Port 4/5/6/7 device.
– Options available: Enabled, Disabled. Default setting is Enabled.

Hot Plug (for Port 4/5/6/7)
– Enable/Disable HDD Hot-Plug function.
– Options available: Enabled, Disabled. Default setting is Enabled.

Spin Up Device (for Port 4/5/6/7)
– On an edge detect from 0 to 1, the PCH starts a COM reset
initialization to the device.
– Options available: Enabled, Disabled. Default setting is Disabled.
(Note) Only appears when HDD sets to RAID Mode.
