Item Code Description
12 PMBUS PMBus Connector
13 ATX 2x12 Pin Main Power Connector
14 SYS_FAN5 System Fan Connector #5
15 P12V_PCIE1 2x3 Pin 12V Power Connector #1
16 P12V_AUX1 2x4 Pin 12V Power Connector (for CPU0)
17 SATA_SGP1 SATA SGPIO Connector
18
CPU0_FAN CPU0 Fan Connector
19 SSATA2 SATA III 6Gb/s Connector #2
20 SSATA0 SATA III 6Gb/s Connector #0
21 SW_RAID VROC Module Connector
22 SL_SATA2 SlimLine SAS 4i Connector #2 (SATA 6Gb/s Signal)
23 SL_SATA1 SlimLine SAS 4i Connector #1 (SATA 6Gb/s Signal)
24 SL_SATA3 SlimLine SAS 4i Connector #3 (SATA 6Gb/s Signal)
25 10GACT2/10GACT1 10G LAN2 Active LED/10G LAN1 Active LED
26 FP_1 Front Panel Header
27 F_USB3 Front Panel USB 3.2 Gen1 Connector
28 SYS_FAN2 System Fan Connector #2
29 SYS_FAN3 System Fan Connector #3
30 SYS_FAN4 System Fan Connector #4
31 M2M_1 M.2 Slot #1 (PCIe Gen4 x4, Support NGFF-22110/2280)
32 M2M_0 M.2 Slot #0 (PCIe Gen4 x4, Support NGFF-22110/2280)
33 IPMB IPMB Connector
34 SPI_TPM TPM Connector
35 BAT Battery Socket
36 LED_BMC1 BMC Firmware Readiness LED
37 BP_1 HDD Backplane Board Connector
38 CASE_OPEN Case Open Intrusion Alert Header
39 CN_NCSI NCSI Connector
40 PCIE_1 PCIe x16 Slot #1 (Gen5 x16)
41 PCIE_2 PCIe x16 Slot #2 (Gen5 x16)
42 PCIE_3 PCIe x16 Slot #3 (Gen5 x16)
43 PCIE_4 PCIe x16 Slot #4 (Gen5 x16)
44 PCIE_5 PCIe x16 Slot #5 (Gen5 x16)
45 PCIE_6 PCIe x16 Slot #6 (Gen5 x16)
46 Accessory EMI Ferrite Core
