Gigabyte MS73-HB2 - Internal Connectors

- 19 -
Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
•
First make sure your devices are compliant with the connectors you wish to connect.
•
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
•
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
CPU1
CPU0
DIMM_P1_L0 DIMM_P1_K0 DIMM_P1_J0 DIMM_P1_I0
DIMM_P1_M0 DIMM_P1_N0 DIMM_P1_O0 DIMM_P1_P0
DIMM_P0_H0 DIMM_P0_G0 DIMM_P0_F0 DIMM_P0_E0 DIMM_P0_A0 DIMM_P0_B0 DIMM_P0_C0 DIMM_P0_D0
17
19
15
1
4
4
3
2
5
6
9
13
14
10
11 12
20
18
8
8
9
8
16
7
1) ATX 11) F_USB3
2) P12V_AUX1 (for CPU0) 12) FP_1
3) P12V_AUX2 (for CPU1) 13) BP_1
4) P12V_PCIE1/P12V_PCIE2 14) SPI_TPM
5) SSATA0/SSATA2 15) IPMB
6) SATA_SGP1 16) CN_NCSI
7) SW_RAID 17) 10GACT2/10GACT1
8) CPU0_FAN1/CPU1_FAN 18) LED_BMC1
9) SYS_FAN1/2/3/4/5 19) BAT
10) PMBUS 20) CASE_OPEN
