Item Code Description
1 VGA VGA Port
2 10GLAN1 10GbE LAN Port #1 (MZ01-CE0 Only)
3 LPC_TPM TPM Module Connector
4 10GLAN2 10GbE LAN Port #2 (MZ01-CE0 Only)
5 SYS_FAN2 System Fan Connector #2
6 USB3_MLAN Server Management LAN Port (top)/ USB 3.0 Ports (bottom)
7 SYS_FAN1 System Fan Connector #3
8 LAN1_2 GbE LAN Port #1 (top)/ Port #2 (bottom)
9 SW_PWR Power Button (top)/ ID Button (bottom)
10 P12V_AUX1 2 x 4 Pin Power Connector (for CPU)
11 CPU0_FAN CPU Fan Connector
12 P12V_AUX2 2 x 4 Pin Power Connector (for Memory)
13 PMBUS PMBus Connector
14 BAT1 System Battery
15 SL_CN1 SlimLine SAS 4i Connector #1 (SATA Signal)
16 SL_CN2 SlimLine SAS 4i Connector #2 (SATA Signal)
17 SL_CN3 SlimLine SAS 4i Connector #3 (SATA Signal)
18 SL_CN4 SlimLine SAS 4i Connector #4 (SATA Signal)
19 ATX1 2 x 12 Pin System Power Connector
20 CASE_OPEN Case Open Intrusion Header
21 FP_1 Front Panel Header
22 BP_1 HDD Back Plane Board Connector
23 F_USB3 Front Panel USB 3.0 Connector
24 IPMB IPMB Connector
25 SYS_FAN5 System Fan Connector #5
26 SYS_FAN4 System Fan Connector #4
27 SYS_FAN3 System Fan Connector #3
28 SYS_FAN6 System Fan Connector #6
29 COM2 Serial Port Cable Connector #2
30 PCIE_1 PCIe x16 Slot #1
31 M2_0 M.2 Connector (PCIe Gen3 x4, NGFF-2280, M-Key)
32 PCIE_3 PCIe x16 Slot #3
33 PCIE_4 PCIe x8 Slot #4
34 PCIE_5 PCIe x16 Slot #5
35 PCIE_7 PCIe x16 Slot #7
36 LED_BMC BMC Firmware Readiness LED
37 COM1 Serial Port Cable Connector #1
To Next Page
