Appendix
Pin connections on the telephone jack
Characters
Standard characters
1) Space
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW average power per channel,
250 mW pulse power
Range Up to 300 m outdoors, up to 50 m indoors
Base power supply 230 V ~/50 Hz
Environmental conditions for
operation
+5°C to +45°C, 20% to 75% relative humidity
Dialling mode DTMF (tone dialling)/PD (pulse dialling)
1x 2x 3x 4x 5x 6x 7x 8x 9x 1
0x
1
1x
1
2x
1
3x
1
4x
1
5x
1 1£$¥¤
2 abc2äáàâãç
I def 3ëéèê
4 gh i4ïíìî
5 jkl5
L mno6öñóòôõ
M pqr s 7ß
N t uv8üúùû
O wxyz9ÿýæøå
Q .,?!0+-:¿¡“‘;_
P * / ( ) <=>%
# #@\ &§
1unused
2unused
3a
4b
5unused
6unused
3
2
1
4
5
6
1)
