MDE-4327B Encore® Canopy Light Kit (M03225K001) Installation Instructions · October 2015 Page 9
Installing Encore Canopy Light Kit
5 Ensure that the cover has been removed from the Unilet.
Figure 3: Assembled Kit with M14407A001 Bracket
Encore Canopy Light
Conduit Bracket (M14407A001)
Note: The view is rotated by 180 degrees.
Note: All conduit assemblies are placed in the same place in the unit regardless of lower
frame type.
