03_14

03_15

03_16

Front light group (03_14, 03_15)

Loosen two of the four rubber retainers on the fork. Draw the front cowl to access to

the rear part. Remove protection «A» to access the bulb. The bulb has a bayonet

coupling, to remove it press gently and twist anticlockwise about 30° and then with-

draw it.

Headlight adjustment (03_16, 03_17)

Place the vehicle over on a horizontal floor in front of a white screen placed at a 10 m

distance, in a darkened area with the vehicle in perpendicular position to the screen.

Start the engine and pull the throttle to 1/3 of its stroke, and turn the headlamp on.

Select low-beam light, the maximum demarcation limit between the dark and the light

area, must result in a height inferior to a 8/10 height from the ground to the centre of

the headlight. The front headlight pointing must be done with screw «A». Before

pointing the headlight, check that the tyres are inflated at the indicated pressure.

CAUTION

LIGHT BEAMS HEIGHT MUST BE WITHIN THE LEGAL LIMITS OF THE COUNTRY

WHERE THE VEHICLE IS USED".

3 Maintenance
