5
1
AC indicator:
On: the monitor is connected to AC power supply;
Off: the monitor is disconnected from AC power supply.
2
Battery status indicator: it displays green and flickers under battery-powered condition, it always
displays orange in charging state and green after fully charged.
Or Running indicator: when the device turns on, this indicator will be lighting, when it tuns off,
this indicator will go out.Please make the object as the standard.
3
MENU：Press this button to call up the SYSTEM MENU, in which the user may set up system
information and perform review operation.
4
NIBP：Press it to inflate the cuff to start a blood pressure measurement. When measuring, press it to
cancel the measurement and deflate the cuff.
5
REC/STOP：Press it to start a real time recording. The recording time can be set in "RT REC TIME"
item under "RECORD" menu.
6
SILENCE：Push this button to suspend the alarm (with 1 minute and 2 minutes selectable), and a
symbol appears in the alarm area. Push this button for more than 1 second to mute all kinds of
sounds (including alarm sound, heart beat, pulse tone, key sound). At the same time, a symbol
appears. Push this button again to restore all kinds of sounds and the symbol disappears from
the screen.
7
FREEZE：Freeze or unfreeze the waveform
8
MAIN：Whatever levels of menu the system is in, press the button and the system will always return
to the main screen.
9
Rotary knob
u Rotating: clockwise or counter-clockwise rotating to move the cursor
u Pressing: press the knob to execute certain operations, such as entering a menu or processing a
command.
10
ON/OFF
u ON: press this button to turn on the monitor
u OFF: in turning on state, keep pressing this button for 3 seconds can turn off the monitor.
11
Alarm indicator: indicating alarm level by different color and flicking frequency
12
handle
