Chapter 3 Installation and Connection
3.1 Appearance
3.1.1 Front Panel
The Gima Vital Pro Monitor with ECG function
Figure 3.1B Front panel illustration for monitor (with ECG function)
Description:
1. " "Alarm indicator
Indicator
Color
Alarm Level
Red flashing
High priority alarm
Yellow flashing
Medium priority alarm
Yellow light
Low priority alarm
Green light
Normal
2. SYS: display of systolic pressure value.
3. DIA: display of diastolic pressure value.
