13
c. Loosen the two mount adjustment bolts that hold the main body of the brake onto the
mounting yoke or fork. These bolts aim forward along the axis of the rotor, with one above and
below the calipers. The holes for these bolts allow for some side-to-side "play" that positions
the caliper mechanism. (Don't take the bolts out; just back off the tension in the bolt enough to
allow the rotor to "shift" a bit on its mounting.)
Once these bolts loosen, squeeze brake lever (brakes are applied) and tighten adjustment bolts
equally – release brake lever only after making sure the bolts are tighten.
d. Loosen cable pinch bolt and screw in barrel adjuster.
