FOLDING & STORAGE
When you are done riding the scooter you can fold it
down for compact storage and transportation. First
remove the seat post and seat, then using one hand, push
down on the folding handle while gently pushing down on
the handlebars. BE CAREFUL NOT TO HIT YOUR HEAD
WITH THE HANDLEBAR, SET YOURSELF AT THE
RIGHT SIDE IS NECESSARY. Push down until you feel
the mechanism lock into the down position.(FIG.15)
BRAKING SYSTEM
(FIG.15)
The scooter is used disc/caliper braking system for the front and rear.They are
both activated by a hand brake lever on the left and right side of the handlebar.
Squeezing the hand brake lever with your left hand activates the rear brake.
Squeezing the hand brake lever with your right hand activates the front brake.
Make sure to release the HAND THROTTLE GRIP when engaging the brakes.
Your scooter is equipped with switches on each brake lever that will disengage
power to the motor when the brake levers are depressed.
Practice braking on a smooth, dry surface to get used to the feel of the braking
system. Braking distance is affected by wet conditions and loose and uneven
riding surfaces.
Adjusting the Brakes
The Brakes on the scooter should come fully adjusted from the factory.
However, it may be necessary to adjust the brakes from time to time.
To adjust the rear brakes:
For brakes that are adjusted too loose:
1. Adjust the tension screw on the right hand brake lever by rotating it
counter-clockwise until the wheel spins freely.
For brakes that are adjusted too tight:
2. Tighten the tension screw on the right hand brake lever by rotating it clockwise
until the wheel has a slight drag.
9
