gio Cobra User Manual

Assembly – Cont:
6. Open outward metal lock at both side of PP
deck and lift PP deck as shown.(FIG.6)
(FIG.6)
7. Insert the 30 amp fuse by opening the PP deck.
Insert the fuse into the fuse holder ,then close
PP deck. （FIG.7）
(FIG.7)
8. Attach the seat post to the seat post
receiver.(FIG.8)
9. Insert the bolt into post holder on the bottom of
frame.make sure to tightening the bolt.(FIG.9)
10. Attach silver lock clamp to the top of the seat post
as shown.(FIG.10)
11.Pull the upper seat post to the desired position and
tighten the lock clamp securely.(FIG.11)
12. Attach the seat to the upper seat post and
tightening the seat bolts as shown.(FIG.12)
(FIG.8)
(FIG.9) (FIG.10)
(FIG.11) (FIG.12)
7

gio Cobra Specifications

General

Brand	gio
Model	Cobra
Category	Scooter
Language	English
