EXCHANGING EMERALD 3000 WITH AND EMERALD
MK3
If it becomes necessary to exchange an original
Emerald 3000 (DX10) lighting controller with an
Emerald MK3 lighting controller then the following
connection changes need to be applied.
230 Volt A.C Connections
Emerald 3000 (DX10) EMERALD MK3
LIVE LIVE
LIGHT A LOAD 1
LIGHT B LOAD 2
NEUTRAL N
12 Volt D.C Connections
S1 S1 ZONE1
S2 S1 ZONE1
S3 S1 ZONE1
S4 S2 ZONE2
S5 S2 ZONE2
S6 S2 ZONE2
AA A1,A2, OR A3 ZONE1
AB A1, A2 OR A3 ZONE2
→ - AUX
SPECIFICATIONS
SUPPLY 230 Vac 50Hz via ELCB/MCB -
unit fused at 13A
12VDC@ 100mA GJD Opal XL (6mA) or Elite
Detectors (10mA) Optional
external 12VDC piezo sounder
up to 50mA
LOAD: Each expansion unit switches
two channels each up to
1500W of resistive load or
1000 Watts of inductive load.
The inductive load may require
a ‘snubber’ (suppressor) to
manage the lamp discharge
current.
INDICATION: Six 24 hour detector indicators
which pulse during detection
and are steady after detection
for the duration of the light on
timer setting.
AUDIBLE Internal warning tone which
sounds on detection day and
night, and is button selectable.
It has a steady tone for zone
one and pulsed tone for zone
two.
CONTROL Controls up to 12 x GJD
detectors. Switches two
independent areas of lighting
with manual override when
required.
OPTIONS
Ability to link both lighting
areas together.
Ability to have a time auxiliary
output.
Ability to active lighting when
linked to an intruder alarm
panel.
DIMENSIONS
146(W) x 86(H) x 56(D) mm
MOUNTING
Indoor use only. Mount in a
clean dry location on a secure
at surface.
TEMPERATURE
-10 to +55 Centigrade
CERTIFICATIONS
Self contained - Class 2 independently mounted control
To Next Page
