The GJD Emerald 3000 MK3 (GJD010) is a dual-area security lighting controller designed to monitor external areas and manage lighting automatically. It can switch up to 3000 Watts of resistive lighting at night for a pre-set period and offers manual override capabilities. The controller includes an audible warning tone and six detector indicators that illuminate upon detection, day or night.

Function Description:

When a detector is activated, the corresponding indicator flickers and remains on for the duration of the timer setting. During darkness, the lighting automatically switches on when the detector receives activation signals and turns off after the pre-set timer period. For automatic lighting control on detection during darkness, the 'Zone 1' and 'Zone 2' green indicators must be selected.

Usage Features:

Detector Indicators: Six 24-hour detector indicators pulse during detection and remain steady after detection for the duration of the light-on timer setting.
- Red Indicator (On): Signifies that the audible warning tone is selected, and Zone 1 and/or Zone 2 indicators are selected to function.
- Indicator (Off): Indicates that the audible warning tone is switched off.
- Green Indicator (On): This mode must be selected for automatic lighting during darkness.
- Green Indicator (Off): Lighting and tone are switched off for this zone.
- Green Indicator (Flashing): A detector has activated the lighting.
- Yellow Indicator (Manually On): Manually selecting this indicator turns the lighting 'on'. Turning it 'off' returns to automatic mode.
- Yellow Indicator (Off): The indicator is off.
- Yellow Indicator (Flashing): A detection has automatically activated the lighting.
Audible Warning Tone: An internal warning tone sounds on detection day and night. It is button-selectable, with a steady tone for Zone One and a pulsed tone for Zone Two.
Manual Override: The system allows for manual override of the lighting.
Pulse Count / Walk Test: This feature assists in locating and aligning detector beams during daylight installations. When detector beams are activated, external lights stay on for 6 seconds.
Pulse Count Settings (1, 2, or 3): After the 'walk test', the pulse count can be set to the required level, which is the number of detector beams that must be crossed to trigger the system.
- 1: Fast response.
- 2: Better immunity with good response.
- 3: Highest immunity to false activation in poor environments but is less responsive.
Auxiliary Output (AUX):
- OFF: Internal sounder and auxiliary output disabled.
- STD: Internal sounder and auxiliary output active, emitting a warning tone on each detection when the tone button is selected.
- 10-30 Seconds: Sets the auxiliary output time after the last detection. The internal sounder operates as per STD.
Light On Time (1 to 24 minutes): Determines the length of time the lighting remains on after the last detection during darkness. Red detector indicators stay on for this time after the last detection, day and night.
Linking Lighting Areas: Both lighting areas can be linked together (except in walk test) by connecting 'LINK' to '-'.
Remote Triggering: Lights can be triggered remotely for the timer period; Pulse Count '1' must be selected.
Intruder Alarm Panel Integration: Zone lighting can be activated for an alarm period when linked to an intruder alarm panel.

Important Technical Specifications:

Supply: 230 Vac 50Hz via ELCB/MCB, unit fused at 13A.
12VDC@ 100mA: Compatible with GJD Opal XL (6mA) or Elite Detectors (10mA). Optional external 12VDC piezo sounder up to 50mA.
Load: Each expansion unit switches two channels, each up to 1500W of resistive load or 1000 Watts of inductive load. Inductive loads may require a 'snubber' (suppressor) to manage lamp discharge current.
Control: Controls up to 12 GJD detectors. Switches two independent areas of lighting with manual override when required.
Dimensions: 146(W) x 86(H) x 56(D) mm.
Mounting: Indoor use only. Mount in a clean, dry location on a secure, flat surface.
Temperature: -10 to +55 Centigrade.
Certifications: CE UKCA, Self-contained - Class 2 independently mounted control.
Diodes: All diodes are IN4148, IN4002 etc.

Maintenance Features:

Factory Settings Adjustment: When connecting the unit to the electrical supply or after an interruption, indicators flash for one minute as the system settles. Pressing any button during this time initiates normal operation.
Installation: To be installed by qualified personnel only.
Exchanging Emerald 3000 with Emerald MK3: If replacing an original Emerald 3000 (DX10) with an Emerald MK3, specific connection changes must be applied for 230 Volt A.C and 12 Volt D.C connections as detailed in the manual.
- 230 Volt A.C Connections:
  - Emerald 3000 (DX10) LIVE to Emerald MK3 LIVE
  - Emerald 3000 (DX10) LIGHT A to Emerald MK3 LOAD 1
  - Emerald 3000 (DX10) LIGHT B to Emerald MK3 LOAD 2
  - Emerald 3000 (DX10) NEUTRAL to Emerald MK3 N
- 12 Volt D.C Connections:
  - S1, S2, S3 to S1 ZONE1
  - S4, S5, S6 to S2 ZONE2
  - AA to A1, A2, OR A3 ZONE1
  - AB to A1, A2 OR A3 ZONE2
  - '-' to AUX
