Header
Reel wrapping in tangled and weedy crops
Possible Cause Correction
Incorrect location of pickup reel.
Place reel ahead and down. Make sure
reel tines clear the sickle with reel in
lowest position.
Reel speed too fast. Reduce speed of reel.
Pickup reel tines pitched too much to
rear.
Adjust tine pitch.
Pickup reel tines bent. Replace or straighten tines.
Crop not divided at header ends. Install or adjust long dividers.
Reel ends wrapping.
Install reel end shields (Flex header).
Install Reel Divider Kit #700957021
(Dynaflex)
Raise reel to reduce amount of straw
gathered by reel.
Crop wrapping on header conveyor (Flex Header)
Possible Cause Correction
Conveyor too high or too low. Adjust conveyor height.
Uneven feed to conveyor. Adjust reel speed and/or location.
Conveyor finger retracting too early or
conveyor fingers too late
Adjust position of conveyor fingers.
14
