SP4-6: Serial Ports
ERNI P/N: 294920 or 101503240001 (12 Poles)
PIN1
RX4 Receive data input RS232
PIN2
TX4 Transmit data output RS232
PIN3
GND
PIN4
TXA0 Transmit data output RS232
PIN5
RXA0 Receive data input RS232
PIN6
+3V3IP IN
PIN7
OUTE
PIN8
TX6 Transmit data output RS232
PIN9
MAN 1=MAN Active
PIN10
RX6 Receive data input RS232
PIN11
+5V
PIN12
GND
microUSB Connector
PIN1
VBUS USB
PIN2
DM
PIN3
DP
PIN4
ID
PIN5
GND
ETH: LAN Ethernet 10/100MB
RJ45
Green Led
Indicate the network link
OFF = link off
ON = link on
Yellow Led
Indicate the flow of data
Blink = data flowing
LL: LED LINK
Off
Contactless reader not powered
After the power on of the device the led indicates the status of the communications in the
following way:
One Flash:
Contactless reader powered, contactless reader violated
Two Flashes:
Contactless reader powered, BV1000R connected
On
Contactless reader powered, communication with the peripherals absent
Each series of flashes is separated with a second of led powered off.
If one or two of the communications are missing the led will skip the related flashes.
