Table of Contents
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Safety instructions (Explanation of the pictograms) . . . . . . . . .6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Initial operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Spraying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Emptying and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Technical data
Pump-upportablesprayers
Typ 2012 Typ 2018
Max. capacity in litres: 12 18
Max. operating temperature: + 40°C + 40°C
Empty weight: 3.5 kg 4.0 kg
Hollow cone nozzle:
Angle of spray: 55° 55°
Quantity reyuired by 1,5 bar: 0.42 l/min 0.42 l/min
by 2,0 bar: 0.49 l/min 0.49 l/min
by 2,5 bar: 0.50 l/min 0.50 l/min
Tank material: Polyäthylen Polyäthylen
Pump material: Polyäthylen Polyäthylen
Mesh size of filter in
quick-connecting valve: 0.9 mm 0.9 mm
Filler funnel strainer
mesh size: 1 mm 1 mm
Residue when emptied
horizontally: ca. 50 ml ca. 50 ml
Configuration:
- all-plastic quick-connecting valve with integreated pressure
gauge
- Brass spray pipe with adjustable cone nozzle 1 mm
- Extension pipe 505 mm long (Type 2018 only)
- Two adjustable padded carrying straps
- Pump lever for right- or left-handed operation
- Pump lever with spray lance park facility
- Container with easy to see contents level indicator
Important Safety Precautions
GLORIA pump-up portable sprayers are used to protect
plants. They should only be used to apply BBA-approved
plant protective agents.
Protect the unit against prolonged exposure to the sun and
against frost.
For safety reasons, do not attempt to spray explosive sub-
stances, corrosive liquids, disinfectants and impregnating
agents or any materials over 40°C.
Carefully follow the instructions of the manufacturer of the
substance to be sprayed. If necessary, wear protective
clothing.
Do not prepare more of thesprayingmixture thanis immedi-
ately required. (Do not pour any leftover amountsdown the
drain.) Dilute any leftover solutions 1:10 and pour it onto
ground that has been cultivated.
Do not eat, drink or smoke while working with plant pro-
tective agents and pesticides until you have finished the
work, removed your protective clothing, carefully cleaned
your hands and face, and rinsed out your mouth.
Do not clear blocked nozzles by blowing through them.
Do not hold the end against you when undoing the spray
tubes.
Warning!
We hereby state explicitly that we accept no liability as per
the Product Liability Law for any damage or injury caused
by our equipment insofar as this was caused by inappropri-
ate repairs or by using replacement parts that were not
GLORIA original spare parts and if the repairs were not car-
ried out by our Customer Service section or an authorized
technician. This also applies to accessories.
Safety instructions
(Explanation of the
pictograms)
I Before initial operation read and observe operating
instructionsand safety information!
Observetheinstructionsofthe manufacturerof the
sprayingagent!
II Wearprotection glovesif necessary!
III Wearprotection clothes if necessary!
